7. On the wiper blade, remove the contact spring. Remove the two screws on either end of the wiper blade.
LEXMARK T650 SERIES • TONER CARTRIDGE REMANUFACTURING INSTRUCTIONS
3232 West El Segundo Blvd., Hawthorne, California 90250 USA • Ph +1 424 675 3300 • Fx +1 424 675 3400 • techsupport@uninetimaging.com • www.uninetimaging.com
© 2009 UniNet Imaging Inc. All trademark names and artwork are property of their respective owners. Product brand names mentioned are intended to show compatibility only. UniNet Imaging does not warrant downloaded information.
6. On the opposite side, turn the locking ring until it spins freely. Carefully pry off the locking ring and white drive gear.
Gently lift the drum up and out of the cartridge, if you are going to reuse the drum, place it in a light protected area.
