3-22 Service Manual
4025-XXX
Storage Device Tests
Quick Disk Test
Selecting this test runs a disk test that performs a non-destructive read/write on one block
per track on the disk.
The following message is displayed while the test is running. The Power indicator also
blinks while the test is in progress.
If the test passes, then the following message is displayed. Press Go, Return, or Stop to
return to the DEVICE TESTS screen.
If the test fails, then the following message is displayed. Press Go, Return, or Stop to
return to the DEVICE TESTS screen.
Cancelling of this test is not allowed.
Disk Test/Clean
This test causes the disk to be low-level formatted. The test destroys all data on the disk
and should not be attempted on a good disk. Normally this test is used only when the disk
contains bad data and is therefore unusable.
Note: This can be an extremely lengthy test; however, the test length depends on the
disk size.
Note: This test leaves the disk unformatted. The CE or user must reformat the disk using
the Format Disk menu operation.
To run this test, select Disk Test/Clean from the DEVICE TESTS menu. The following
message is displayed to warn the customer that all disk contents are lost. To continue
with the test, press Go. To exit the test immediately and return to the DEVICE TESTS
screen, press Return or Stop. The Power indicator also blinks while the test is in
progress.
Quick Disk Test
Testing...
Quick Disk Test
Test Passed
Quick Disk Test
Test Failed
Files will be
Lost. Go/Stop?
