Parts catalog 7-55
7462
Go Back
Previous
Next
Assembly 27: MFP 4-bin mailbox assembly #2
Asm-
Index
Part
number
Units/
option
Units/ kit
or pkg
Description
1 40X4644 1 1 Top media bin bail
2 40X4642 1 1 Top cover
3 40X4135 3 1 1st - 3rd media bail
4 40X4640 1 1 Left cover
5 40X4638 1 1 Left rear inner cover
6 40X4369 1 1 Sensor (deflector gate HP)
7 40X4632 1 1 Rear door assembly
8 40X4637 1 1 Right rear inner cover
9 40X4639 1 1 Right cover
10 40X4636 1 1 LED card assembly
11 40X4139 4 1 Media output bin light pipe
