Assembly 4: Control panel
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0903 1 1 Model plate (CX825) ‑‑
1 41X0904 1 1 Model plate (XC8155) ‑‑
1 41X0905 1 1 Model plate (XC8160) ‑‑
241X0544 1 1Bezel, 10.1‑inch control panel ‑‑
341X0052 1 1Board, 10.1‑inch control panel ‑‑
4 41X0224 1 1 Button kit, 10.1‑inch control panel
“Control panel button kit
removal” on page 646
5 41X0215 1 1 Support, 10.1‑inch control panel ‑‑
6 41X0238 1 1 Control panel support cover --
7 41X0222 1 1 Sensor (proximity) ‑‑
8 41X0221 1 1 Proximity sensor cover --
7564
Parts catalog
