Assembly 5: Duplex
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0133 1 1 Duplex drive gears
“Duplex drive gears removal” on
page 608
2 41X0123 1 1 Duplex lower pinch roller
guide
--
3 41X0121 1 1 Duplex turn guide --
4 41X0066 1 1 Front nip release arm --
5 41X0072 1 1 Lower duplex sensor bracket --
6 41X0446 1 1 Sensor (duplex path 2) --
7 41X0446 1 1 Sensor (duplex path 1) --
8 41X0071 1 1 Upper duplex sensor bracket --
9 41X0065 1 1 Rear nip release arm --
10 41X0098 1 1 Connector cover, plastic
“Plastic connector cover
removal” on page 612
11 41X0105 1 1 Duplex
“Left door, duplex, and MPF
removal” on page 613
12 41X0122 1 1 Duplex upper guide --
7564
Parts catalog
