Lexmark XC8160 Service Manual

Assembly 6: Left door
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0173 1 1 Left door support strap --
2 41X0100 1 1 Left door damper --
3 41X0073 1 1 Connector cover, metal --
4 41X0684 1 1 Sensor (MPF paper present) --
5 41X0058 1 1 MPF media present actuator --
6 41X0914 1 1 Sensor (MPF/pass‑through)
“Sensor (MPF/pass-through)
with deflector removal” on
page 622
741X0120 1 1Deflector with sensor
(MPF/pass-through)
“Sensor (MPF/pass-through)
with deflector removal” on
page 622
841X0172 1 1MPF tray stop
“MPF tray stop removal” on
page 619
941X0119 1 1MPF pick guide
“MPF pick guide removal” on
page 617
10 41X0124 1 1 Left door paper guide --
11 41X0081 1 1 Left door front catch --
12 41X0174 1 1 Left door support --
13 41X0080 1 1 Left door rear catch --
14 41X0101 1 1 Left door
“Left door, duplex, and MPF
removal” on page 613
15 41X0136 1 1 Left door release latch --
16 41X0135 1 1 Duplex release latch
“Duplex release latch removal”
on page 608
17 41X0059 1 1 MPF tray front actuator --
18 41X0250 1 1 Left door rod
“Door rod cover removal” on
page 656
19 41X0993 1 1 Pick roller
“MPF pick roller removal” on
page 616
20 41X0167 1 1 MPF pick shaft --
21 41X0060 1 1 MPF tray rear actuator --
22 41X0176 1 1 MPF tray
“Left door, duplex, and MPF
removal” on page 613
