Assembly 8: Frame
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0074 1 1 Frame connector bracket --
241X0131 1 1Right handle --
3 41X0991 1 1 Tray close rail, right --
4 41X0103 1 1 PC unit/developer door
“Developer unit and photoconductor
unit removal” on page 646
5 41X0992 1 1 Tray close rail, left --
6 41X0130 1 1 Left handle --
