Assembly 2: Covers 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0089 1 1 Rear left cover
“Rear left cover removal” on page
673
2 41X0099 1 1 Connector access cover --
3 41X0088 1 1 Rear lower cover
“Rear lower cover removal” on
page 672
441X0092 1 1Right cover
“Right cover removal” on page 629
5 41X0070 1 1 Right cover bracket --
641X0090 1 1Vent cover
“Vent cover removal” on page 628
740X9079 1 1Audio speaker --
841X0094 1 1Lower front cover
“Lower front cover removal” on
page 664
9 41X0097 1 1 Door rod cover
“Door rod cover removal” on
page 656
10 41X0093 1 1 Inner lower cover
“Inner lower cover removal” on
page 650
11 41X0715 1 1 Inner upper cover
“Inner upper cover removal” on
page 649
12 41X0096 1 1 Left lower cover --
13 41X0091 1 1 Left front cover --
7564
Parts catalog
1270
