Assembly 3: Covers 3
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0234 1 1 Scanner right upper cover --
2 41X0231 1 1 Scanner right cover
“Flatbed scanner right cover
removal” on page 733
3 41X0235 1 1 Scanner front upper cover
“Flatbed scanner front upper cover
removal” on page 732
4 41X0232 1 1 Scanner front cover --
5 41X0229 1 1 Keyboard access cover --
6 41X0780 2 1 Front door strap --
7 41X0227 1 1 Front door
“Front door removal” on page 651
8 41X0781 2 1 Support spring --
9 41X0278 1 1 Cable cover --
10 41X0230 1 1 Scanner left cover
“Flatbed scanner left cover
removal” on page 733
11 41X0233 1 1 Scanner left upper cover --
12 41X0236 1 1 Scanner rear cover
“Flatbed scanner rear cover
removal” on page 735
7564
Parts catalog
1272
