Technical Specifications
Operating Voltage range 10-16 VDC
Current Consumption
@12 VDC: 0.6 A continuous, 1.3 A Peak consumption
(max duration 40 msec)
Dark Current Consumption 20 mA (standby current)*
Radiation Noise Level Reference is E-Marking certification for Lexus Hotspot
*standby current condition: the power switch is in OFF position but the ACC is ON
Data Rate (Maximum) HSPA: (DL/UL)14.4 / 5.76 Mbps
WCDMA PS: UL 384 kbps/DL 384 kbps
WCDMA CS: UL 64 kbps/DL 64 kbps
EDGE: DL 236.8 kbps/UL: 236.8 kbps
GPRS:UL 85.6 kbps/DL 85.6 kbps
GSM CS: UL 9.6 kbps/DL 9.6 kbps
3G bands UMTS: 2100/900 MHz
2G bands GSM: 1900/1800/900/850 MHz
Operating Temperature -20 to 65° C
Storage Temperature -40 to 85° C
Humidity 5 %~ 95 %
