4-3. Do-it-yourself maintenance
Fuse Ampere Circuit
8
D-J/B ALT 80 A
OBD, D P/SEAT, TI&TE, AM1,
S/ROOF, D-IG1-1, D-IG1-2, D-IG1-3,
D-IG1-4, D-ACC, PWR OUTLET,
PANEL, climate control seat system
9
PTC HTR 60 A PTC HTR 1, PTC HTR 3
10
LUG-J/B ALT 50 A
PTL, RL SEAT, B/ANC, FUEL OPN,
RR S/SHADE, PSB, RR-IG1-1,
RR-IG1-2, RR-IG1-3, RR-ACC,
RR-CIG
11
RR A/C 30 A Air conditioning system
12
AIR SUS 40 A
Electronically modulated air suspen-
sion system
13
HTR 50 A Air conditioning system
14
NOISE FILTER 40 A Condenser
15
DEFOG 40 A Rear window defogger
16
PTC HTR 2 50 A PTC heater
17
H-LP CLN 30 A Headlight cleaner
18
EPS 80 A EPS
19
EFI 80 A
VVT, ETCS, ABS MAIN 1, EDU1,
EDU2, A/F, ECU-IG, IGN, INJ, P-J/B
20
E/G RM B 80 A
D/C CUT 1, FR CTRL BAT, EPS ECU,
ABS MAIN 2, ABS MTR2, ST,
H-LP RL, H-LP LL
21
EFI NO.1 40 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
22
E/G RM B2 30 A ABS MAIN 3, EPS ECU, D/C CUT 2
