47
1-1. For safe use
1
LX570_450d_OM_OM60R63E_(GE)
For safety and security
SRS airbag system components
Knee airbags
Curtain shield airbags
Front passenger airbag
Side impact sensors (front door)
Front side airbags
SRS warning light and “RSCA OFF”
indicator light
Side impact sensors (rear)
Rear side airbags (second outboard
seat)
Driver airbag
Driver’s seat belt buckle switch
Safing sensor (rear)
Airbag sensor assembly
Front impact sensors
Seat belt pretensioners and force
limiters (front seats)
Driver’s seat position sensor
“RSCA OFF” switch
“AIR BAG ON” and “AIR BAG
OFF” indicator lights (if equipped)
Airbag manual on-off switch (if
equipped)
Seat belt pretensioners (second
outboard seats)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
