PICTORIAL INDEX
xi
Page
1 Fuel gauge 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Voltmeter 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Odometer and trip meter 41. . . . . . . . . . . . . . . . . . . . .
4 Odo/Trip knob 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Automatic transmission second start
indicator light 210. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Automatic transmission indicator lights 203. . . . . .
7 Turn signal indicator light 25. . . . . . . . . . . . . . . . . . . .
8 Headlight high beam indicator light 25. . . . . . . . . . .
9 Overdrive−off indicator light 205. . . . . . . . . . . . . . . . .
10 ”PWR” mode indicator light 205. . . . . . . . . . . . . . . . .
11 Active traction control system indicator light 225.
12 Tachometer 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Active height control indicator lights 221. . . . . . . . .
14 Engine oil pressure gauge 39. . . . . . . . . . . . . . . . . . . .
15 Engine coolant temperature gauge 38. . . . . . . . . . . .
16 Brake system warning light 43. . . . . . . . . . . . . . . . . . .
17 Low washer fluid warning light 49. . . . . . . . . . . . . . . .
Page
18 Open door warning light 47. . . . . . . . . . . . . . . . . . . . . .
19 Headlight indicator light 24. . . . . . . . . . . . . . . . . . . . . .
20 SRS warning light 45. . . . . . . . . . . . . . . . . . . . . . . . . . . .
21 Vehicle skid control system OFF
indicator light 228. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22 Vehicle skid control system and active
traction control system warning light 226, 228. . . . .
23 Slip indicator light 227. . . . . . . . . . . . . . . . . . . . . . . . . .
24 Center differential lock indicator light 211. . . . . . . .
25 Cruise control indicator light 213. . . . . . . . . . . . . . . .
26 Unengaged ”Park” warning light 47. . . . . . . . . . . . . .
27 Automatic transmission fluid temperature
warning light 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28 Malfunction indicator lamp 45. . . . . . . . . . . . . . . . . . .
29 Driver’s seat belt reminder light 44. . . . . . . . . . . . . . .
30 Anti−lock brake system warning light 46. . . . . . . . . .
31 Instrument panel light control dial 51. . . . . . . . . . . . .
32 Low fuel level warning light 49. . . . . . . . . . . . . . . . . . .
33 Discharge warning light 49. . . . . . . . . . . . . . . . . . . . . .
To Next Page
