COMFORT ADJUSTMENT
136
Installation with 3−point type seat belt
(A) Infant seat installation
16X103b
An infant seat is used in rear−facing position only
.
16x273
CAUTION
If the driver
’
s seat position does not allow sufficient
space for safe installation, install the child restraint
system on the second right seat.
