LFA RTP 9 - Page 86

86
Upper Support Columns
The Upper Support Columns (2) hold up the
Upper Roller Cam Housing. Order at https://
www.lfatabletpresses.com/rtp-9-upper-support-
column
Upper Support Nuts
The Upper Support Nuts are fixed onto the
Upper Support Columns. Order at https://www.
lfatabletpresses.com/rtp-9-upper-support-nut
Main Cam Shaft
The Main Cam Shaft sits inside the Upper Roller
Cam Housing and the Turret. It is a major driving
force in the RTP 9®'s operation. Order at https://
www.lfatabletpresses.com/rtp-9-main-cam-shaft
Upper Roller Cam Housing
The Upper Roller Cam Housing contains the
Upper Roller Cam, the Upper Support Columns,
and the Main Cam Shaft. Order at https://www.
lfatabletpresses.com/rtp-9-upper-pressure-cam-
housing
Motor
The Motor electrically powers the RTP 9® and
is located under the Gearbox. Order at https://
www.lfatabletpresses.com/rtp-9-motor
Gearbox
The Gearbox is driven by the Motor to initiate
the RTP 9®'s operation. Order at https://www.
lfatabletpresses.com/rtp-9-gearbox
