88
Food Grade Point of Contact Parts
Contact Part Material
Turret Cast iron 250
Ejection Tray SUS304
Hopper SUS304
Tooling
(Upper Punches, Lower Punches, and Dies)
User specified
Fill Tray Tin bronze QSN-6-3
Fill Tray Scraper and Take-Off Blade Bakelite and copper coat Zn
Technical Specifications
Tooling Specification RTP Tooling
Number of dies 9
Production capacity 16,200/hr
Max diameter of tablet 12 mm (round)
14 mm (irregular)
Max fill depth 15 mm
Thickness of tablet 6 mm
Max pressure 40 kN
Number of filling stations 1
Double layered tablet No
Kilowatts 1.5 kW
Volts 240 V (110 V on request)
Amps 13 A
Overall size 1029 mm x 470 mm x 665 mm
Weight 260 kg (573 lbs)
Floor loading (static) 0.8 kN/m2
Correct belt tension (new) 290.25 N
Correct belt tension (run-in) 193.5 N
