1. Application range
This specification is applied to LP81A chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
(1) Temperature : 25 ± 5°C(77 ± 9°F), CST : 40 ± 5°C
(2) Humidity : 65% ± 10%
(3) Power : Standard input voltage (100-240V~, 50/60Hz)
* Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 20 minutes prior
to the adjustment.
3. Test method
(1) Performance : LGE TV test method followed
(2) Demanded other specification
Safety : CE, IEC Specification
EMC : CE, IEC
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. General Specification(LCD Module)
Item Specification Measurement Result Remark
Display Screen Device 26” wide Color Display Module Resolution:1366X768
32” wide Color Display Module Resolution:1366X768
Aspect Ratio 16:9
LCD Module 26” TFT WXGA LCD 26” HD MAKER : LGD
32” TFT WXGA LCD 32” HD MAKER : LGD
Operating Environment 1) Temp. : 0 ~ 40 deg LGE SPEC
2) Humidity : 0 ~ 85%
Storage Environment 1) Temp. : -20 ~ 60 deg
2) Humidity : 0 ~ 85 %
Input Voltage AC100-240V~, 50/60Hz
Power Consumption Power on (Blue) : LF15R Volume: 1/8 volume of sound distortion point
≤ 110W 26” HD
≤ 160W 32” HD
St-By (Red) ≤ 1.0 W
