LG 22LF15R Service Manual

LGE Internal Use OnlyCopyright © 2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
- 7 -
5. Model Specification(NON EU)
Remark
China(DK) Australia(BG)
VHF/UHF C1~C62 C1~C75
CATV S1~S41 S2~S44
Rear
Rear, Audio Out (8Ω) for commercial china
Rear
L/R Input
Specification
NON EU, CHINA
PAL SECAM B/G/D/K, PAL I/II, NTSC-M
BAND PAL NTSC
VHF/UHF E2~C69 2~78
CATV S1~S47 1~71
Upper Heterodyne
PAL, SECAM, NTSC
PAL, SECAM, NTSC
Y/Cb/Cr, Y/ Pb/Pr
HDMI-DTV, Only PCM MODE
Component (1EA), AV (1EA)
Item
Market
Broadcasting system
Available Channel
Receiving system
Video Input (1EA)
AV Output (1EA)
Component Input (1EA)
HDMI Input (1EA)
Audio Input (2EA)
Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed
720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I)
720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I)
720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50Hz
720*480 31.47 59.94 27.000 SDTV 480P
720*480 31.50 60.00 27.027 SDTV 480P
720*576 31.25 50.00 27.000 SDTV 576P 50Hz
1280*720 44.96 59.94 74.176 HDTV 720P
1280*720 45.00 60.00 74.250 HDTV 720P
1280*720 37.50 50.00 74.25 HDTV 720P 50Hz
1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz,
1920*1080 33.72 59.94 74.176 HDTV 1080I
1920*1080 33.75 60.00 74.25 HDTV 1080I
1920*1080 56.25 50 148.5 HDTV 1080P
1920*1080 67.432 59.94 148.350 HDTV 1080P
1920*1080 67.5 60.00 148.5 HDTV 1080P
6. Component Video Input (Y, PB, PR)
