Resolution H-freq.(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed Remark

720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I) Spec. out but display

720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I)

720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50Hz

720*480 31.47 59.94 27 SDTV 480P

720*480 31.5 60 27.027 SDTV 480P

720*576 31.25 50 27 SDTV 576P

1280*720 44.96 59.94 74.176 HDTV 720P

1280*720 45 60 74.25 HDTV 720P

1280*720 37.5 50 74.25 HDTV 720P

1920*1080 28.125 50 74.25 HDTV 1080I

1920*1080 33.72 59.94 74.176 HDTV 1080I

1920*1080 33.75 60 74.25 HDTV 1080I

1920*1080 56.25 50 148.5 HDTV 1080P

1920*1080 67.432 59.94 148.350 HDTV 1080P

1920*1080 67.5 60.00 148.5 HDTV 1080P

1920*1080 27 24 74.25 HDTV 1080P

1920*1080 33.75 30 74.25 HDTV 1080P

7. HDMI input (DTV)
