6. RGB PC INPUT Mode Table
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1. 720X400 31.468 70.08 28.321
2. 640X480 31.469 59.94 25.17 VESA
37.684 75.00 31.50
3. 800X600 37.879 60.31 40.00 VESA
46.875 75.00 49.50
4. 832X624 49.725 74.55 57.283 Macintosh
5. 1024X768 48.363 60.00 65.00 VESA(XGA)
56.470 70.00 75.00
60.123 75.029 78.75
6. 1280X768 47.693 59.99 80.125 VESA(WXGA)
7. 1360X768 47.649 59.94 84.625 VESA(WXGA)
8. 1366X768 47.649 59.94 84.625 Supported
9. 1280X1024 63.981 60.020 108.00 VESA(SXGA)
10 1440X900 55.469 59.901 88.750 CVT Red. Blanking
11. 1440X900 55.935 59.887 106.5 CVT
12. 1400X1050 64.744 59.948 101.00 CVT Red. Blanking
13. 1400X1050 65.317 59.978 121.750 CVT
14. 1680X1050 64.674 59.883 119.00 CVT Red. Blanking
15. 1680X1050 65.290 59.954 146.25 CVT
16. 1920X1080 66.647 59.988 138.625 WUXGA
7. HDMI DTV Table
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Remark Proposed
1. 720X480 31.47 59.94 27.00 SDTV 480p 60Hz(4:3)
2. 720X480 31.50 60 27.027 SDTV 480p 60Hz(4:3)
3. 640X480 31.50 59.94 25.175 SDTV 480p 60Hz(4:3)
4. 640X480 31.50 60 25.20 SDTV 480p 60Hz(4:3)
5. 720X480 31.47 59.94 27.00 SDTV 480p 60Hz(16:9)
6. 720X480 31.47 60 27.027 SDTV 480p 60Hz(16:9)
7. 720X576 31.25 50.00 27.000 SDTV 576p 50Hz
8. 1280X720 45.00 50.00 74.176 HDTV 720p 50Hz HDCP
9. 1280X720 44.96 59.94 74.176 HDTV 720p 60Hz HDCP
10. 1280X720 44.96 60 74.250 HDTV 720p 60Hz HDCP
11. 1920X1080 28.13 50.00 74.250 HDTV 1080i 50Hz HDCP
12. 1920X1080 33.72 59.94 74.176 HDTV 1080i 60Hz HDCP
13. 1920X1080 33.75 60 74.250 HDTV 1080i 60Hz HDCP
14. 1920X1080 27 24 74.250 HDTV 1080P 24Hz HDCP
15. 1920X1080 56.25 50.00 148.500 HDTV 1080P 50Hz HDCP
16. 1920X1080 67.43 59.94 148.352 HDTV 1080P 60Hz HDCP
17. 1920X1080 67.50 60 148.500 HDTV 1080P 60Hz HDCP
