LG 22M34D - Setting up the Monitor Set 25 19 M35 D; Attaching the Stand Base 26 20 M35 A; Detaching the Stand Base 28 20 M35 D

6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Attach the
StandBody
to the monitor set.
Attach the
StandBase
.
Tighten the screw to the right.
SettinguptheMonitorset
AttachingtheStandBase
1
Place the Monitor set with the screen side
down on a flat and cushioned surface.
Lay a foam mat or soft protective cloth
on the surface to protect the screen from
damage.
CAUTION
2
StandBase
StandBody
1
2
3
DetachingtheStandBase
1
Place the Monitor set with the screen side
down on a flat and cushioned surface.
StandBase
StandBase
StandBody
StandBody
Pull out the
StandBody
and
StandBase
from the monitor set.
Turn the screw to the left.
Pull out the
StandBase
.
1
2
3
2
