ENGLISH
25
MAKING CONNECTIONS
Euro Scart connection
Transmits the video and audio signals from an external device to the TV. Connect the external device
and the TV with the Euro Scart cable as shown on the following illustration. To display images by using
progressive scan, make sure to use the Euro Scart cable.
2
PC)
MONO
DVD / Blu-Ray / HD Cable Box
(Not Provided)
Any Euro scart cable used must be signal shielded.
NOTE
Output Type
Current
input mode
AV1 (TV Out
1
)
Digital TV Digital TV
Analogue TV Analogue TV
Component, AV, HDMI, RGB
Analogue TV
1 TV Out : Outputs Analogue TV or Digital TV signals.
