LG 27BL55UB Service Manual

- 4 - Copyright © 2019 LG Electronics Inc. All rights reserved.
Only training and service purposes
SPECIFICATION
1. General Specification
No Item Content Measurement Result Remark
1 Customer BRAND
Checked BRAND : LGE
Product
2 User Model Name 27UL550 / 27UL500/27BL55U Checked 1pole stand
3 Sale region Worldwide Checked
4 Feature 27 ”LCD MONITOR (ADS UHD HDR)
Checked ADS =BOE IPS
name
5 Chassis Name LM8CA
Checked PCB, Product
spec., Adjustment
spec.
6
General
Scope
External SW
& Adj.
Joystick switch
Up / Down / Left /
Right / OK
Checked
Press and Hold :
Power off
Function
Picture Mode, Ratio, S.E.S, Six Color, On
Screen Control,HDR10, Dual Controller,
Factory Calibration
Checked
7 Input
HDMI IN
HDMI1(2.0) / HDMI2 (2.0) /HDMI1(1.4) /
HDMI2 (1.4)
Checked
DP IN
Display Port(1.4) /Display Port(1.2) /Display
Port(1.1)
Checked
Display Port(1.4)
Î for HDR
function
USB-C IN N/A N/A Do not provide
USB DN N/A N/A Do not provide
H/P OUT Audio L/R Checked
RS-232C N/A N/A Do not provide
8 Power Cord
Length 1.55±0.05m: 1.55m
Refer to Suffix
standard and
power cord Table.
Weight 0.174kg ± 10%, 0.173kg
Color White Checked
9 Cable
Phone to
RS-232
Length 0.2 ± 0.01m N/A
Do not provide
Weight 0.02kg ± 10%, N/A
Color Black N/A
USB C To C
Cable
Length 1.8 ± 0.03m N/A
Do not provide
Weight 0.0775kg ± 5% N/A
Color White N/A
Impedance
1) CABLE : 90 Ω±15Ω
2) CONNECTOR : 90
Ω±10Ω
N/A
DisplayPort
Length 1.50m±0.05m 1.5m
P/N :
EAD63749403
Weight 0.136kg ± 10% 0.135kg

LG 27BL55UB Specifications

General

Brand	LG
Model	27BL55UB
Category	Monitor
Language	English
