PRODUCT SPECIFICATION
LCD Screen Type TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Screen
Color Depth HDMI 8-bit color is supported.
DP (DisplayPort) 8-bit color is supported.
Pixel Pitch 0.31125 mm x 0.31125 mm
Resolution Max Resolution 1920 x 1080 @ 240 Hz
Recommended Resolution 1920 x 1080 @ 60 Hz
Operating Frequency HDMI Horizontal Frequency 30 kHz to 255 kHz
Vertical Frequency 48 Hz to 240 Hz
DP Horizontal Frequency 30 kHz to 255 kHz
Vertical Frequency 48 Hz to 240 Hz
Input Connector
, DP (DisplayPort) IN, USB ( ) 1/2, HDMI IN 1/2, USB UP ( )
Power Sources Power Rating 19 V
3.3 A
Power Consumption
(Typical)
Operating Mode: 30 W (Typical)*
Sleep Mode: ≤ 0.5 W
Off Mode: ≤ 0.3 W
AC/DC Adapter DA-65G 19, manufactured by Asian Power Devices Inc.
LCAP39, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE
Output: 19 V
3.42 A
