ENGLISH
9
ASSEMBLING AND PREPARING
Parts and buttons
All of the buttons are touch sensitive and can be operated through simple touch with your finger.
NOTE
Touch button Description
Scrolls through the saved programmes.
Adjusts the volume level.
OK Selects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menus, or saves your input and exits the menus.
INPUT Changes the input source.
/ I
Turns the power on or off.
(19 V )
COMPONENT IN
AUDIO IN(PC)
HP
AV2 IN / AUDIO L R
HDMI IN
5 V 5 V 0.5 A 1.0 A
13/18 V
700 mA Max
LND IN
Remote Control Sensor
Standby Light
Lighting On: Turned off
Lighting Off: Turned on
Connection panel (See p.17)
Touch buttons on the
bottom of the TV
