Reference: Power Consumption Settings
The following tables assume that Installer Menu item 118 POWER SAVINGS is set to 3 (default)
and Installer Menu item 099 BACK LIGHTING is set as shown below (default value is 255).
Note: Values are results of controlled experiments under laboratory conditions.
Item 099
Back Lighting
(Static)
22LX570M 28LX570M 32LX570M 43LX570M
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
100
18.5 100.00% 23.6 100.00% 39.0 100.00% 55.6 100.00%
90
17.9 32.19% 22.6 40.65% 38.1 68.53% 52.1 93.71%
80
17.7 31.83% 22.3 40.11% 37.3 67.09% 51.3 92.27%
70
17.4 31.29% 21.8 39.21% 36.6 65.83% 49.3 88.67%
60
17.1 30.76% 21.4 38.49% 35.4 63.67% 47.8 85.97%
50
16.7 30.04% 20.7 37.23% 34.0 61.15% 45.5 81.83%
40
16.4 29.50% 20.2 36.33% 32.2 57.91% 43.6 78.42%
30
15.1 27.16% 18.2 32.73% 29.3 52.70% 36.9 66.37%
20
14.2 25.54% 16.8 30.22% 25.9 46.58% 31.5 56.65%
10
13.0 23.38% 14.9 26.73% 22.5 40.47% 24.9 44.78%
1
12.0 21.58% 13.4 24.10% 19.5 35.07% 19.7 35.43%
Item 099
Back Lighting
(Dynamic)
22LX570M 28LX570M 32LX570M 43LX570M
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
200
18.5 100.00% 23.6 100.00% 38.9 100.00% 55.7 100.00%
190
17.9 32.14% 22.6 40.57% 38.1 68.40% 52.2 93.72%
180
17.7 31.78% 22.4 40.13% 37.3 66.97% 51.3 92.10%
170
17.3 31.06% 21.9 39.23% 36.6 65.71% 49.3 88.51%
160
17.1 30.70% 21.4 38.37% 35.4 63.55% 47.9 86.00%
150
16.7 29.98% 20.7 37.16% 34.4 61.76% 45.5 81.69%
140
16.3 29.26% 20.2 36.27% 32.6 58.53% 43.6 78.28%
130
15.0 26.93% 18.2 32.68% 29.6 53.14% 36.9 66.25%
120
14.2 25.49% 16.8 30.07% 26.3 47.22% 31.5 56.55%
110
13.0 23.34% 14.8 26.64% 22.9 41.11% 25.0 44.88%
101
12.1 21.72% 13.4 24.06% 19.8 35.55% 19.7 35.37%
