PREPARATION
ANTENNA/
CABLE IN
Antenna or Cable Connection
1. Antenna (Analog or Digital)
Wall Antenna Socket or Outdoor Antenna without a Cable Box Connections.
For optimum picture quality, adjust antenna direction if needed.
ANTENNA/
CABLE IN
2. Cable
NOTE
a If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.
a For much more information about antennas visit our Knowledgebase at http://
lgknowledgebase.com. Search for antenna.
Wall
Antenna
Socket
Outdoor
Antenna
(VHF, UHF)
Cable TV
Wall Jack
Copper Wire
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
RF Coaxial Wire (75 Ω)
RF Coaxial Wire (75 Ω)
Be careful not to bend the copper
wire when connecting the antenna.
