EXTERNAL EQUIPMENT SETUP
OTHER A/V SOURCE SETUP
1. How to connect
1
Connect the AUDIO/VIDEO jacks
between TV and external equipment.
Match the jack colors
.
(
Video = yellow, Audio Left = white, and
Audio Right = red
)
2. How to use
ᯫ
Select the AV or AV1/2 input source on
the TV using the
INPUT button on the
remote control.
ᯫ
Operate the corresponding external
equipment.
IN 3
H/P USB IN
AV IN 2
VIDEO
AUDIO
L(MONO)
R
L R
VIDEO
Camcorder
Video Game Set
