SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. Electrical specification
4.1. Model Specification
1. Application range
This spec sheet is applied to LCD TV used LP91J chassis.
2. Specification
Each part is tested as below without special appointment.
1) Temperature : 25±5ºC (77±9ºF), CST : 40±5ºC
2) Relative Humidity : 65±10%
3)
Power Voltage
: Standard input voltage(100~240 V@50/60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety: CE, IEC specification
- EMC : CE, IEC
No Item Specification Remark
1. Market Central and South America
2. Broadcasting system NTSC, PAL-M, PAL-N
3. Available Channel BAND NTSC
VHF 2~13
UHF 14~69
CATV 1~125
4. Receiving system Upper Heterodyne
5. Video Input NTSC, PAL-M/N 22LK310 : Rear 1EA,
26/32LK310 : Rear 1EA, Side 1EA
6. Component Input Y/Cb/Cr, Y/ Pb/Pr Rear
7. RGB Input RGB-PC, S/W Upgrade Rear
8. HDMI Input HDMI-DTV, Only PCM MODE 26/32LK310 Rear 2EA
22LK310 Rear 1EA
9. Audio Input (4EA) PC Audio, Component, AV (2EA) L/R Input (22LK310/311: AV Audio Input 1EA)
10. RS-232C Remote control, Commercial control Rear
11. USB Input (1EA) Divx, MP3, JPEG Only Side
