(6) In case of an unusual display in HDMI mode
(7) In case of an unusual display in SCART1 mode
(8) In case of an unusual display in SCART2 mode
Is the HDMI002(IC1004)
normal?
Yes
Same as Block A
Are Input voltage, IIC Communication
and HV sync normal?
No
Is the Video input of the
A/V Jack(J1200) normal?
Yes
Same as Block A
Check the input source.
No
Replace the IC.
No
Is the Video input of the
A/V Jack(J1201) normal?
Yes
Same as Block A
Check the input source.
No
To Next Page
