MAKING CONNECTIONS
Connection overview
Connect various external devices to the ports on the TV back panel.
1
Find an external device you want to connect to your TV as shown on the following illustration.
2
Check the connection type of the external device.
3
Go to the appropriate illustration and check the connection details.
HDMI – See p.84
DVI – See p.84
Component – See p.84
Composite –See p.86
Digital – See p.87
HDMI – See p.86
DVI – See p.86
RGB – See p.86
HDMI – See p.84
DVI – See p.84
Component – See p.84
Composite – See p.86
Euro Scart – See p.85
Composite – See p.86
Euro Scart – See p.85
Memory storage –
See p.88
Memory card reader –
See p.88
HDMI – See p.84
Component – See p.84
Composite – See p.86
HD Receiver DVD VCR
Speaker
USB
PC
Gaming device
If you connect a gaming device to the TV, use the cable supplied with the gaming device.
