13
EXTERNAL EQUIPMENT SETUP
VIDEO
AUDIO
COMPONENT IN
AV 2 AV 1
ANTENNA
IN
HDMI IN
12
RGB IN(PC)
VIDEO
AUDIO
COMPONENT IN
HDMI IN
12
1
RGB IN(PC)
VIDEO
AUDIO
COMPONENT IN
VARIABLE
OUT
HDMI INHDMI IN
AUDIO IN
(RGB/DVI)
HDMI/DVI IN
HDMI/DVI INHDMI/DVI IN
1
2
Connect the DVI output of the digital set-top box to the
HHDDMMII//DDVVII IINN 11
jack on the set.
Connect the audio output of the digital set-top box to the
AAUUDDIIOO IINN((RRGGBB//DDVVII))
jack on the set.
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
Select
HDMI1 input source with using the
IINNPPUUTT
button on the remote control.
2
3
4
1
When connecting with a HDMI to DVI cable
