SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. General Specification
No. Item Specification Remark
1. Display Screen Device 32/37/42" wide Color Display Module
2. Aspect Ratio 16:9
3. LCD Module 32/37/42" TFT WXGA LCD Maker : LPL
4. Operating Environment Temp. : 0 ~ 40 deg
Humidity : 0 ~ 85 %
5. Storage Environment Temp. : -20 ~ 60 deg
Humidity : 0 ~ 85%
6. Input Voltage AC100 ~ 240V, 50/60Hz
7. Power Consumption Power on (Green)
(42")Total 168.36W (Typ.) (Logic=6.36W, Backlight=162W )
(37") Total 126Watt (Typ.) (Logic=6W, Backlight =120W )
(32")Total 114.32W (Typ.) (Logic=4.32(4.1)W, Backlight =110W )
St-By (Red) : 1.0 W
8. Type Size 760.0 x 450.0 x 48.0 32"
877.0 x 516.8 x 55.5 37"
1006 x 610 x 56 42"
9. Pixel Pitch 0.17025 x 0.51075 32"
0.200 x 0.600 37"
0.227 x 0.681 42"
10. Back Light 18 EEFL 32"
20 EEFL 37"
20 CCFL 42"
11. Display Colors 16.7M (16,777,216)
12. Coating 3H, AG
1. Application range
This spec sheet is applied to the 42"/37" LCD TV used LD74A
chassis
2. Specification
Each part is tested as below without special appointment.
(1) Temperature : 25 ± 5°C(77 ± 9°F), CST : 40 ± 5°C
(2) Relative Humidity : 65% ± 10%
(3) Power Voltage : Standard input voltage (100-240V~,
50/60Hz)
*Standard Voltage of each products is marked by models
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 20 minutes prior
to the adjustment.
3. Test method
(1) Performance : LGE TV test method followed
(2) Demanded other specification
Safety : CE, IEC Specification
EMC : CE, IEC
