5. LCD Module
No Item Min Typ Max Unit Maker
1 Luminance 400 500 cd/m
2
50cm from the surface
(W/O PC mode) -Full White Pattern
2
View angle (R/L, U/D)
178/178 degree 32", 37" 42"
3 Color Coordinate White X Typ. 0.279/0.279/0.279 Typ.
Y -0.03 0.292/0.292/0.292 +0.03
Red X 0.635/0.636/0.635
Y 0.339/0.343/0.344
Green X 0.282/0.284/0.286
Y 0.606/0.615/0.614
Blue X 0.145/0.144/0.146
Y 0.064/0.063/0.061
Contrast ratio 600 800 32"
(W/O PC mode) 700 900 37"
800 1000 42"
5 Luminance Variation 1.3
6. Component Video Input (Y, PB, PR)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1. 720*480 15.73 60.00 SDTV, DVD 480i
2. 720*480 15.63 59.94 SDTV, DVD 480i
3. 720*480 31.47 59.94 480p
4. 720*576 15.625 50.00 SDTV, DVD 625 Line
5. 720*576 31.25 50.00 HDTV 576p
6. 1280*720 45.00 50.00 HDTV 720p
7. 1280*720 44.96 59.94 HDTV 720p
8. 1920*1080 31.25 50.00 HDTV 1080i
9. 1920*1080 33.75 60.00 HDTV 1080i
10. 1920*1080 33.72 59.94 HDTV 1080i
