LG 42LX6500 Service Manual

- 4 -
LGE Internal Use OnlyCopyright © 2010 LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
4. Module General Specification
1. Application range
This specification is applied to the LCD TV used LD03R
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 ºC ± 5 ºC(77 ºF ± 9 ºF), CST: 40 ºC ± 5 ºC
2) Relative Humidity : 65 % ± 10 %
3) Power Voltage
: Standard input voltage (AC 100-240 V~ 50 / 60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC :CE, IEC
No. Item Specification Remark
1 Display Screen Device 107 cm(42 inch) wide color display module
2 Aspect Ratio 16:9
3 LCD Module 107 cm(42 inch) TFT LCD FHD 240 Hz(Edge)
4 Operating Environment Temp. : 0 deg ~ 50 deg
Humidity : 20 % ~ 90 %
5 Storage Environment Temp. : -20 deg ~ 60 deg
Humidity : 10 ~ 90 %
6 Input Voltage AC 100-240V~, 50 / 60Hz
7 Power Consumption Power on (White) LCD (Module) + Backlight(EDGE LED)
LGD Typ : 112.2(Edge)
8 Module Size 973.2 (H) x 566.2 (V) x 10.8 mm(D)
8 Pixel Pitch 0.4845 (H) x 0.4845 (V)
9 Back Light LED(EDGE)
10 Display Colors 1.06 B(true) colors
11 Coating 3H

LG 42LX6500 Specifications

General

Display diagonal	42 \
Audio system	Dolby Digital
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	Yes
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Power consumption (standby)	0.1 W
Power consumption (typical)	150 W
Annual energy consumption	156 kWh

Weight and Dimensions

Depth (with stand)	270 mm
Height (with stand)	692 mm
Weight (with stand)	19000 g
Depth (without stand)	29.3 mm
Width (without stand)	1016 mm
Height (without stand)	630 mm
Weight (without stand)	16700 g
