LG 42PC1D Service Manual

SPECIFICATIONS
NOTE : Specifications and others are subject to change without notice for improvement .
V Application Range
This spec is applied to the 42” PLASMA TV used PD61A Chassis.
V Specification
Each part is tested as below without special appointment.
1) Temperature : 25±5°C (77±9°F), CST : 40±5
2) Relative Humidity: 65±10%
3) Power Voltage: Standard Input voltage (100-240V~, 50/60Hz)
* Standard Voltage of each product is marked by models.
4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with SBOM.
5) The receiver must be operated for about 20 minutes prior to the adjustment.
V Test Method
1) Performance : LGE TV test method followed.
2) Demanded other specification
Safety : CE, IEC specification
EMC : CE, IEC
V General Specification
1. Module Specification
- 10 -
Display Screen Device
Aspect Ratio
PDP Module
Operating Environment
Storage Environment
Input Voltage
1
2
3
4
5
6
No Item Specification Remark
42” wide Color Display Module
16:9
42PC1D = PDP42V3
42PC1DV = PDP42V8
RGB Closed Type, Film Filter
1)Temp. : 0~40deg
2)Humidity : 0~85%
3)Temp. : -20~60deg
4)Humidity : 0~85%
100-240V~, 50/60H
Plasma Display Panel
LGE SPEC.
Maker : Sony/ LG Innotek/ Sanken
Chassis
PD61A 42PC1D/DV-EC The United Kingdom LG
Model Name Market Brand Remark
42PC1D/DV-EC Safety : IEC/EN60065
EMI : EN55013
EMS : EN55020
The United Kingdom
TEST
Model ApplianceMarket Remark

LG 42PC1D Specifications

General

Depth	98.5 mm
Height	695 mm
Weight	30000 g
Comb filter	3D
Pixel pitch	- mm
Power supply	250 W
Product color	Black, Silver
Audio (L/R) in	1
Display diagonal	42 \
Sound output mode	6
Depth (with stand)	380 mm
Display brightness	1200 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Power requirements	100-240V, 50/60Hz
Width (with stand)	1129 mm
Height (with stand)	748.5 mm
SCART ports quantity	3
USB 2.0 ports quantity	No
Viewable size diagonal	107 mm
Contrast ratio (typical)	-
Viewing angle, horizontal	160 °
Analog signal format system	NTSC, PAL, SECAM
Power consumption (standby)	1 W
