LG 43UP80 Series User Manual

10
Wall Mounting Bracket
(Depending on model)
Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in the
following table.
A
Model
43/50UP77*
43/50UP78*
43/50UP80*
43/50UP81*
55/60/65UP77*
55/65UP78*
55/60/65UP80*
55/65UP81*
Screws distance (A) (mm) 200 300
Standard screw M6 M6
Number of screws 2 2
Wall mount bracket WB21LMB WB21LMB
A
B
Model
43/50UP75*
43/50UP77*
43/50UP78*
43/50UP80*
43/50UP81*
55UP75*
55UP77*
55UP78*
55UP80*
55UP81*
65UP75*
60/65UP77*
65UP78*
60/65UP80*
65UP81*
70/75UP77*
70/75UP78*
70/75UP80*
70/75UP75*
82/86UP80*
VESA (A x B) (mm) 200 x 200 300 x 300 300 x 300 400x400 600x400
Standard screw M6 M6 M6 M6 M8
Number of screws 4 4 4 4 4
Wall mount bracket
LSW240B
MSW240
OLW480B
MSW240
OLW480B LSW440B LSW640B
