Daisy Chain Monitors
Use this function when displaying ANALOG RGB inputs of a PC to the other product.
• To use different products connected to each other Connect one end of the signal input cable (15-pin
D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB IN
connector of other products
DVI Cable
RGB Cable
15-pin D-Sub Signal Cable
(Max 3m)
DVI Cable
(Max 3m)
y
When multi-connecting in/out cascade format, no loss cables are recommended.
y
Since the image quality may decrease when multiple monitors are connected, we recommend that
you use an amplifier.
NOTE
