24
ENGLISH
PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
refers to alternating current (AC), and refers to direct current (DC).
LCD screen Screen type Thin Film Transistor (TFT)
Liquid Crystal Display (LCD) Screen
Video signal Maximum resolution 1920 x 1080 @ 60 Hz
- This may not be supported on some OS or graphic card
types.
Recommended
resolution
1920 x 1080 @ 60 Hz
- This may not be supported on some OS or graphic card
types.
Horizontal frequency RGB : 30 kHz to 83 kHz
HDMI/OPS/DVI-D/DISPLAYPORT : 28,1 kHz to 83 kHz
Vertical frequency RGB : 50 Hz to 75 Hz
HDMI/OPS/DVI-D/DISPLAYPORT : 50 Hz to 60 Hz
Synchronization Separate Sync, Digital
Input/ Output ports SPEAKER OUT,AUDIO IN/OUT,LAN, PIXEL SENSOR, HDMI,
IR&LIGHT SENSOR, DP IN/OUT, DVI-D, USB, RGB,
RS-232C IN/OUT
Embedded battery Applied
Environmental
Conditions
Operating Temperature
Operating Humidity
0 °C to 40 °C
10 % to 80 %
Storage Temperature
Storage Humidity
-20 °C to 60 °C
5 % to 85 %
* Applicable only for models that support the speakers
Audio/AUDIO RMS Audio Output 10 W + 10 W (R + L)
Input Sensitivity 0.7 Vrms
Speaker Impedance 8 Ω
