4.5. OPS (PC Mode )
No. Section Pol. Dot Clock
[MHz]
Frequency
[kHz]/[Hz]
Total
Cycle
(E)
Display
(A)
Front
Porch(B)
Sync.
(D)
Back
Porch(F)
Resolution
1 H(Pixels) - 25.175 31.469 800 640 16 96 48 640 x 480
V(Lines) - 59.94 525 480 10 2 33
2 H(Pixels) + 40 37.879 1056 800 40 128 88 800 x 600
V(Lines) + 60.317 628 600 1 4 23
3 H(Pixels) - 65 48.363 1344 1024 24 136 160 1024 x 768
V(Lines) - 60 806 768 3 6 29
4 H(Pixels) - 81.75 53.783 1520 1152 64 120 184 1152 x 864
V(Lines) + 59.959 897 864 3 4 26
5 H(Pixels) + 74.25 45 1650 1280 110 40 220 1280 x 720
V(Lines) + 60 750 720 5 5 20
6 H(Pixels) - 83.5 49.702 1680 1280 72 128 200 1280 X 800
V(Lines) + 59.81 831 800 3 6 22
7
H(Pixels) + 85.5 47.712 1792 1366 70 143 213 1366 x 768
V(Lines) + 59.79 798 768 3 3 24
8 H(Pixels) + 108 63.981 1688 1280 48 112 248 1280 x 1024
V(Lines) + 60.02 1066 1024 1 3 38
9 H(Pixels) + 108 60 1800 1600 24 80 96 1600 x 900
V(Lines) + 60 1000 900 1 3 96
10 H(Pixels) - 146.25 65.29 2240 1680 104 176 280 1680 x 1050
V(Lines) + 59.954 1089 1050 3 6 30
11 H(Pixels) + 148.5 67.5 2200 1920 88 44 88 1920 x 1080
V(Lines) + 60 1125 1080 4 5 46
4.6. Component(Y/Pb/Pr)
Resolution H-freq(kHz) V-freq(Hz)
1 720*576 15.625 50.00 SDTV, DVD 576i
2 720*576 31.25 50.00 EDTV 576p
3 1280*720 45.00 60.00 HDTV 720p
4 1280*720 37.5 50 HDTV 720p
5 1280*720 44.96 59.94 HDTV 720p
6 1920*1080 31.25 50.00 HDTV 1080i 50Hz For Australian
7 1920*1080 56.25 50 HDTV 1080P 50Hz
8 1920*1080 33.75 60.00 HDTV 1080i 60Hz (ATSC)
9 1920*1080 33.72 59.94 HDTV 1080i 59.94Hz
10 1920*1080 67.5 60 HDTV 1080P 60Hz
4.7. CVBS(AV, Composite)
Resolution H-freq(kHz) V-freq(Hz)
1 NTSC, PAL - - All of NTSC and PAL
