*. Adj. condition and cautionary items
1) Lighting condition in surrounding area Surrounding lighting
should be lower 10 lux. Try to isolate adj. area into dark
surrounding.
2) Probe location
- LCD: Color Analyzer (CA-210) probe should be within 10cm
and perpendicular of the module surface (80°~ 100°)
3) Aging time
- After Aging Start, Keep the Power ON status during 5
Minutes.
- In case of LCD, Back-light on should be checked us-
ing no signal or Full-white pattern.
5.3.6. Reference (White balance Adj. coordinate and
color temperature)
▪ Luminance: 255 Gray
▪ Standard color coordinate and temperature using CS-1000 (over
26 inch) [applied only LGD Module]
▪ Standard color coordinate and temperature using CA-210(CH 14)
[applied only LGD Module]
5.3.7. Color coordination according to aging time
▪ Luminance: 255 Gray, 100IRE
▪ Standard color coordinate and temperature using CA-
210(CH-14) – by aging time
Cool Medium Warm
Aging time
(Min)
X Y X Y X Y
Target 269 273 279 292 313 329
1 0~1 274 281 284 300 318 335
2 2~3 273 280 283 299 317 334
3 4~5 272 279 282 298 316 333
4 6-9 272 278 281 296 316 332
5 10-19 271 277 281 295 314 331
6 20-35 270 275 280 294 313 330
7 36-49 270 275 279 294 313 330
8 50-79 269 274 279 293 313 329
9 80-119 269 273 279 293 313 329
10 Over 120 269 273 279 292 313 329
5.4. Ship-out mode check (In-stop)
▪ After nal inspection, press In-Stop key of the Adj. R/C and
check that the unit goes to Stand-by mode
6. GND and HI-POT Test
6.1 Method
1) GND & HI-POT auto-check preparation
- Check the Power Cable and Signal Cable insertion condi-
tion.
2) GND & HI-POT auto-check
a. Pallet moves in the station. (POWER CORD / AV CORD is
tightly inserted)
b. Connect the AV JACK Tester.
c. Controller (GWS103-4) on.
d. GND Test (Auto)
- If Test is failed, Buzzer operates.
- If Test is passed, execute next process (Hi-pot test). (Re-
move A/V CORD from A/V JACK BOX)
e. HI-POT test (Auto)
- If Test is failed, Buzzer operates.
- If Test is passed, GOOD Lamp on and move to next
process automatically
6.2 Check Point
1) Test voltage
- GND: 1.5KV/min at 100mA
- SIGNAL: 3KV/min at 100mA
2) TEST time: 1 second
3) TEST POINT
- GND Test = POWER CORD GND and SIGNAL CABLE
GND.
- Hi-pot Test = POWER CORD GND and LIVE & NEUTRAL.
4) LEAKAGE CURRENT: At 0.5mArms
7. Audio Output Check
No. Item Min Typ Max Unit Remark
1 Audio Line Out
0.4 0.5 0.6 Vrms
RGB, DVI, HDMI, DP,
OPS, USB (No load)
0.25 0.35 0.45 Vrms
AV, Component (No
load)
Mode
Coordinate
Temp ∆uv
x y
Cool 0.269 0.273 13,000K 0.0000
Medium 0.279 0.292 10,000K 0.0000
Warm 0.313 0.329 6,500K 0.0000
Mode
Coordinate
Temp ∆uv
x y
Cool 0.269±0.001 0.273±0.001 13,000K 0.0000
Medium 0.279±0.001 0.292±0.001 10,000K 0.0000
Warm 0.313±0.001 0.329±0.001 6,500K 0.0000
