SPECIFICATION
1. Application range
This specication is applied to the LW56C chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F),
CST: 40 °C ± 5 °C
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
: Standard input voltage (AC 100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
4) Specication and performance of each parts are followed
each drawing and specication by part number in accord-
ance with BOM.
5) The receiver must be operated for about 20 minutes prior to
the adjustment.
No. Item Specication Remarks
1 Supported Sync. Type Separate Sync, Digital
2 Operating Frequency
Analog
Horizontal 30 ~ 83 kHz
Vertical 56 ~ 75 Hz
DVI/OPS
Horizontal 30 ~ 83 kHz
Vertical 56 ~ 60 Hz
HDMI
Horizontal 30 ~ 83 kHz
Vertical 56 ~ 60 Hz
Display
Port
Horizontal 30 ~ 83 kHz
Vertical 56 ~ 60 Hz
3 Resolution
Input
RGB. 1920×1080 @ 60Hz
DVI/OPS 1920×1080 @ 60Hz
HDMI 3840x2160 @ 30Hz Recommend : 1920*1080@60Hz
Display Port 3840x2160 @ 30Hz Recommend : 1920*1080@60Hz
Output Display Port 3840x2160 @ 30Hz
3.1. RGB, DVI-D, HDMI, Display Port (PC) Specication
3. General Specication
