PRODUCT INSTALLATION
Installing an LVDS Cable
The LVDS cable port is located as shown in the figure below.
When installing the product, make sure there is enough space to install the LVDS cable.
LVDS cable is optional and not provided with the product.
Connect the cable when the scaler board is off.
Make sure to connect the cable correctly.
38 mm
26 mm
297 mm
38 mm
26 mm
297 mm
LVDS Cable (not included)
LVDS Cable (not included)
47/55WFB
49WFB
CAUTION
NOTE
To Next Page
