Power
P1100
AZ1117D
(IC1104)
+3.3V_AVDD_SIF +3.3V_AVDD_AU +3.3V_AVDD_LPLL
+5V_ST(6A)
AZ1085S-3.3V
IC1105 +3.3V_VDDP
+3.3V_AVDD_MPLL +3.3V_IR +3.3V_AVDD_OTG +3.3V_AVDD_ADC +3.3V_AVDD_MEMPLL
+2.5V_DDR +2.5V_VDD_DDR
AZ1085S
IC1102
+5V
+3.3V_TU +3.3V_CI
AZ1117D
(IC1103)
+16V(1.3A)
IC1000(AMP)_PVDD
Stand-byStand-by
P_12V(1A)
KA7809ERTM
(IC1109)
+5V_TU
MOSFET
(Q1102)
+3.3V_VDDP_ST
500Ohm
BEAD
+1.25V_ST
+1.25V_VDDC +1.25V_AVDD_DVI
+1.8_TU
AZ1117D
(IC1108)
+1.8_AMP
AZ1117D
(IC1106)
+3.3V_AVDD
POWER_ON/OFF1
KIA7805AF
(IC1110)
+5V_GENERAL
+5V_CI
500Ohm
BEAD
AZ1117D
(IC1107)
+12V_SC
500Ohm
BEAD
SB : 50 mA 1.4 A (D), 1.28 (A) / Max : 1.5 A
0.59 A (Max : 0.65 A)
0.48 A (Max : 0.55 A)
0.76 A (D), 0.62 (A) /Max : 0.9 A
0.008 A / Max : 0.0020
0.1 A / Max : 0.37A 0.33 A / Max : 1.41 A
0.035 A
0.29 A
0.003 A 0.001 A
0.0083 A
0.022 A
0.48 A (Max : 0.55 A)
0.001 A
0.05 A 0.04 A 0.003 A
0.055 A 0.04 A
0.22A
D : 0.39A A : 0.25A
D : 0.27A A : 0.04A
0.16A
0.03A
