A-7
PREPARATION
BACK COVER FOR WIRE
ARRANGEMENT
■ Image shown may differ from your TV.
After Connecting the cables as necessary, install
Cable Holder as shown and bundle the cables.
Cable Holder
SWIVEL STAND
■ This feature is not available for all models.
After installing the TV, you can adjust the TV set
manually to the left or right direction by 20 degrees
to suit your viewing position.
■ Image shown may differ from your TV.
When installing the wall-mounted unit,use the pro-
tection cover. Insert the Protection cover into the
TV until clicking sound.
NOT USING THE DESK-
TYPE STAND
Protection Cover
Power Supply
Circuit breaker
EARTHING
Ensure that you connect the earth wire to prevent
possible electric shock. If grounding methods are
not possible, have a qualified electrician install a
separate circuit breaker.
Do not try to earth the TV by connecting it to tele-
phone wires, lightening rods or gas pipes.
(Fixate the unit so that the guide is on the outer side.)
To Next Page
