ITAITALIANO
DIAGRAMMI A BLOCCHI
37
(Solo EC97**, EC98**)
AUDA/D
BB_TP_DATA
DAC_DATA
AAD_DATA
HSR_P/M
CVBS
DIF(P/N)
SIF
Tuner
COMP/AV2/DVI_ L/R
AV2
COMP
AV2_CVBS
Comp Y,Pb,Pr
H13
LG1154AN
Audio AMP (4ch~4.2ch)
OPTIC
SPK
H/P
H/P Audio L/R
SPDIF
I2S
16x2
DDR3
4Gb×
6 (1600)
Vx1
CVBS
SCART
SC_CVBS, RGB, Audio L/R
DTV/MNT_LR/V_OUT
LNB
H/P AMP
H13
LG1154D
CI
eMMC
CI
HDMI 2.0
Switch
HDMI1~4
TS output
From H13D
D14
1Gb x 4 (1866)
DDR3
HDMI output
Motion-R &
USB1(USB3.0)
USB2(USB2.0)
USB3(USB2.0)
USB HUB
HDMI_CEC
USB 3.0
USB 2.0
USB 2.0
USB_CAM
USB 2.0 (Wi-Fi 11ac & BT)
USB_Wi-Fi
PHY
RMII
LAN
WOL / WOW
Logo Light
Logo Light
Logo Light
IR/Joy key
RS-232C
8x4
8
16x4
U14
1Gb x 2(1866)
DDR3
FHD HS-LVDS
16x2
2:1 Mux
2:1 Mux
1:2 Splitter
OSD HS-LVDS
URSA9
1Gb x 4 (1866)
DDR3
16x4
Vx1 8Lane
Vx1 2Lane
OSD
