5.3. HDMI Input(PC/DTV)
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
PC DDC
1 640*350 31.468 70.09 25.17 EGA X
2 720*400 31.469 70.08 28.32 DOS O
3 640*480 31.469 59.94 25.17 VESA(VGA) O
4 800*600 37.879 60.31 40.00 VESA(SVGA) O
5 1024*768 48.363 60.00 65.00 VESA(XGA) O
6 1152*864 54.348 60.053 80.002 VESA O
7 1360*768 47.712 60.015 85.50 VESA (WXGA) X
8 1280*1024 63.981 60.020 108.00 VESA (SXGA) O
9 1920*1080 67.5 60 148.5 HDTV 1080P O
DTV
1 640*480 31.469 59.94 25.175 SDTV 480P
2 640*480 31.5 60 25.200 SDTV 480P
3 720*480 31.50 60 27.027 SDTV 480P
4 720*480 31.47 59.94 27.00 SDTV 480P
5 1280*720 45.00 60.00 74.25 HDTV 720P
6 1280*720 44.96 59.94 74.176 HDTV 720P
7 1920*1080 33.75 60.00 74.25 HDTV 1080I
8 1920*1080 33.72 59.94 74.176 HDTV 1080I
9 1920*1080 67.50 60.00 148.50 HDTV 1080P
10 1920*1080 67.432 59.94 148.352 HDTV 1080P
11 1920*1080 27.00 24.00 74.25 HDTV 1080P
12 1920*1080 26.97 23.976 74.176 HDTV 1080P
13 1920*1080 33.75 30.000 74.25 HDTV 1080P
14 1920*1080 33.71 29.97 74.176 HDTV 1080P
5.4. 3D HDMI Input(1.4b)
No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) 3D input proposed mode Proposed
1
720*480p 62.938/63 59.94 / 60 54.00 F/P,L/A
31.469/31.5 27.00 T/B,S/S,S/S Full
2
1280*720p 89.91/90.00 59.94 / 60 148.5 F/P, L/A
44.96 / 45 74.17/74.25 S/S, T&B, S/S Full
3
1920*1080i 67.432 / 67.5 59.94 / 60 148.35/148.5 F/P, F/A
33.72/33.75 74.25 S/S, T&B, S/S Full
4
1920*1080p 26.97 / 27 23.97 / 24 74.175/74.25 S/S, T&B, S/S Full
28.125 25 148.5
33.716/33.75 29.976/30 74.18/74.25
43.94/54 23.97/24 148.35/148.5 F/P, L/A
25
67.432/67.5 29.976/30 148.35/148.5
67.432/67.5 59.94/60 148.35/148.5 T/B,S/S
