DVI to HDMI Connection
1. How to connect
1
Connect the DVI output of the PC to the HDMI/
DVI IN 1, 2, 3, or 4* jack on the TV.
2
Connect the PC audio output to the AUDIO IN
(RGB/DVI) jack on the TV.
2. How to use
ᯫ
Turn on the PC and the TV.
ᯫ
Select the HDMI1, HDMI2, HDMI3, or HDMI4* input
source on the TV using the INPUT button on the
r
emote control.
DVI OUTPUT
AUDIO
RGB IN (PC)
LAN
WIRELESS
CONTROL
VIDEO A
U
L(MONO)
VIDEO
AUDI
AUDIO OUT
1
/DVI IN
2
3
1
(RGB/DVI)
AUD O IN
YP B P R
L
OPT CAL D GITAL
RS-232C
I
( SERVICE ON
L
ꔡ
1
2
* HDMI4: For 50/60PK750
