2. Digital / Analog TV Video
3. AV Video
Check RF Cable & Signal
Check Tuner 3.3V Power
L1600
Replace L1600 or Tuner
Check IF_P/N Signal
TU1601 6/7 Pin
Check Mstar LVDS Output
Replace Mstar(IC101) or Main Board.
ok
ok
ok
No
No
No
Bad Tuner. Replace Tuner.
Check input signal f ormat.
Is it supported?
Check AV Cable f or damage
for damage or open conductor
Check JK1702, CVBS Signal Line
R237
ok
ok
ok
No
Replace Jack
ok
Check CVBS_DET Signal
R1713
Replace R1713 or R1710
No
Check Mstar LVDS Output
Replace Mstar(IC101) or Main Board.
No
