5.2. HDMI Input (DTV / PC)
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel
clock(MHz)
Proposed Remarks
DTV
1 640*480 31.46 59.94 25.125 SDTV 480P
2 640*480 31.5 60.00 25.125 SDTV 480P
3 720*480 15.73 59.94 13.500 SDTV 480I Spec. out, but display
4 720*480 15.75 60.00 13.514 SDTV 480I Spec. out, but display
5 720*480 31.47 59.94 27.000 SDTV 480P
6 720*480 31.5 60.00 27.027 SDTV 480P
7 1280*720 44.96 59.94 74.176 HDTV 720P
8 1280*720 45 60.00 74.250 HDTV 720P
9 1920*1080 33.72 59.94 74.176 HDTV 1080I
10 1920*1080 33.75 60.00 74.250 HDTV 1080I
11 1920*1080 26.97 23.97 74.176 HDTV 1080P
12 1920*1080 27.00 24.00 74.250 HDTV 1080P
1920*1080 33.71 29.97 74.176 HDTV 1080P
1920*1080 33.75 30.00 74.250 HDTV 1080P
1920*1080 67.43 59.94 148.352 HDTV 1080P
1920*1080 67.5 60.00 148.500 HDTV 1080P
PC
1 640*350 31.46 70.09 25.17 EGA X
2 720*400 31.46 70.08 28.32 DOS O
3 640*480 31.46 59.94 25.17 VESA(VGA) O
4 800*600 37.87 60.31 40.00 VESA(SVGA) O
5 1024*768 48.36 60.00 60.00 VESA(XGA) O
6 1152*864 54.34 60.05 80.00 VESA O
7 1280*1024 63.98 60.02 108.0 VESA (SXGA) O Full HD model Only
8 1360*768 47.71 60.01 85.50 VESA (WXGA) O
9 1920*1080 67.5 60.00 148.5 WUXGA(CEA 861D) O Full HD model Only
